| Features |
| Management |
HTTP/HTTPS, PPP, CLI, SNMP (read/write), Digi Port Authority-Remote management diagnostics and auto-discovery tool |
| Protocols |
UDP/TCP, DHCP/RARP/ARP-Ping for IP Address assignment, Extended Telnet RFC 2217, Telnet, Reverse Telnet, Modbus to Modbus/TCP protocol conversion support |
UDP/TCP, Supports multiple unicasts, DHCP/RARP/ARP-Ping for IP Address assignment, Extended Telnet RFC 2217, Telnet, Reverse Telnet, Modbus to Modbus/TCP protocol conversion support |
UDP/TCP, DHCP/RARP/ARP-Ping for IP Address assignment, Extended Telnet RFC 2217, Telnet, Reverse Telnet, Modbus to Modbus/TCP protocol conversion support |
| Software |
Supports Digi’s Realport® COM port redirector |
| Security |
SSHv2, SSL/TLS |
| Extended Safety |
N/A |
Conformal coated circuit board, NEMA TS 2 compliant, Screw terminal connector for power |
Conformal coated circuit board, Screw terminal connector for power, Ships in "Latency Mode & TCP Keepalive" setting |
| Status LEDs |
Link, Power, Activity, Status |
| Operating Systems |
AIX, HP-UX, Solaris, Linux®, Windows® 2000, Windows® XP, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10, Windows Server® 2003, Windows Server® 2008, Windows Server® 2012. Note: TCP/UDP socket services are operating system independent |
Dimensions
(L x W x D) |
5.25 in x 3.33 in x 0.95 in (13.34 cm x 8.46 cm x 2.42 cm) |
| Weight |
2.25 oz (64.00 g) |
| Other |
Full modem and hardware flow control, Modem emulation, Port buffering, RJ45-DB-9F console adapter included for optional serial configuration, Wall mount kit included |
Full modem and hardware flow control, Modem emulation, Port buffering, RJ-45/DB-9F crossover adapter included for optional serial configuration |
| Interfaces |
| Serial |
| Ports |
1/2/4 RS-232/422/485 RJ-45 (switch-selectable); Up to 230 Kbps throughput; Signal support for TXD, RXD, RTS, CTS, DTR, DSR, DCD |
4 RS-232/422/485 RJ-45 (switch-selectable); Up to 230 Kbps throughput; Signal support for TXD, RXD, RTS, CTS, DTR, DSR, DCD |
| Ethernet |
| Physical Layer |
1 RJ-45 10/100 Mbps 10/100Base-T (auto-sensing); Full or half duplex |
| Power Requirements |
| Power Input |
9-30 VDC |
9-30 VDC @ 0.5 Amps max (screw terminal power) |
9-30 VDC @ 0.5 Amps max (screw terminal power) |
| Power Supply |
12 VDC extended temperature power supply sold separately; Bare-wire “pigtail” power connector included |
9-30 VDC @ 525 mA max |
Optional 12 VDC extended temperature power supply sold separately |
| Power Consumption |
Typical: 4 W; Max: 6 W |
| Surge Protection |
4 kV burst (EFT) per EN61000-4-4, 2 kV surge per EN61000-4-5 |
| Environmental |
| Operating Temperature |
-35° C to +74° C (-31° F to 165° F) |
| Storage Temperature |
-40° C to +85° C (-40° F to +185° F) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Ethernet Isolation |
1500VAC min per IEEE802.3/ANSI X3.263 |
| Serial Port Protection (ESD) |
15 kV human body model |
| Approvals |
| Safety |
UL/CL60950, IEC60950, CB |
Class 1 Division 2, UL/CL60950, IEC60950 & CB |
Class 1 Division 2, UL/CL60950, IEC60950 |
| Emissions/Immunity |
CE, FCC Part 15 (Class A), EN55024, EN55022 Class A, AS/NZS 3548, VCCI V-3/99 .05 |
